LUBRICANTS IN PERSPECTIVE

LUBRICANTS ARE NOT COMMODITIES.

Lubricant performance can vary greatly between competing mineral and competing synthetic oils. Because these quality differences directly and significantly impact the ultimate cost of operating and maintaining the rotating equipment, lubricant purchases cannot be effectively managed as a commodity. Lubricant excellence must always be purchased. Even the most effective lubricant management practices cannot impart properties to a lubricant that it doesn’t possess.

JUST THE FACTS

Royal Purple lubricants consistently deliver at a higher level of performance across a broader group of equipment than other industrial oils, including the synthetic oils offered by our largest competitors. No other lubricant offers a lower Total Cost of Ownership for the majority of your plant equipment. The cost reductions consistently exceed the total cost of the product, often within a few weeks as illustrated by the examples below.

TOTAL ROYAL PURPLE SAVINGS IN PERSPECTIVE

THE BIG PICTURE

$3,000,000 Maintenance Costs

$90,000 Lubrication Expense is part of this $3M.

$12,000,000 Energy Costs

• Example is based on 36,000 HP (electrically driven) operating 8,000 hours per year at $0.05 kwh power cost.
• Lubricant purchases are 3% of the maintenance costs.
• Lubricant purchases are 3% to 4% of the energy costs.
• Although conceptually accurate, expense ratios will vary from plant to plant.

ROTATING EQUIPMENT COST SAVINGS USING ROYAL PURPLE

The following pie chart illustrates the savings attainable across a broad population of equipment from upgrading to Royal Purple lubricants.

• Energy savings are typically greater than 3%.
• Need for equipment repair is reduced by at least 30%.
• Although Royal Purple lubricants may cost more per gallon, the annual cost for lubricants changes little due to greatly extended drain intervals and the elimination of oil changes associated with equipment repairs.
• Total Savings: $1,260,000
  • Annual return on oil investment is 1,400%.
  • 90-day ROI based on energy savings.
  • 37-day ROI based on maintenance savings.
  • 26-day ROI based on combined energy and maintenance savings is $25 per HP.
  • Annual Energy Savings is $10 per HP.
  • Annual Maintenance Savings is $25 per HP.
• Even a total elimination of current lubricant costs would produce insignificant savings compared to the savings routinely attained from upgrading to Royal Purple lubricants.
• A Rohm & Hass Operational Excellence model estimates that for each dollar saved in maintenance, $3 to $7 in economic benefits accrue to other areas via improved quality, inventory reductions, energy savings, safety and increased uptime ($2.7M to $6.3M for this example).

PURCHASING YOUR WAY TO IMPROVED PROFITABILITY

Most cost-savings initiatives intended to reduce maintenance costs and improve rotating equipment reliability are very time-intensive and people-intensive. Royal Purple offers significant improvements and cost savings by simply replacing a product that you already buy and use. It doesn’t get any easier.

THE CONUNDRUM

Your current supplier is delivering the message you want to hear: that the best value is attained by maintaining tradition and purchasing major brand quality at competitive prices, often with the opportunity to further reduce purchase costs by consolidating your purchases. Royal Purple is delivering the message that our lubricants produce savings that dwarf your total expenditure for lubricants. Both of us can’t be right. While a part of you would like to believe these savings are possible, it just doesn’t seem plausible that they can be achieved by just changing lubricants.

BELIEVE IT

The primary job of a lubricant is to reduce friction and protect lubricated components (energy and wear). Most rotating equipment repairs are due to the failure of lubricated components, mainly bearings. Therefore, it makes perfect sense that truly superior lubrication will deliver energy and maintenance savings.

BE PREPARED

When your current supplier learns that you are considering any use of Royal Purple lubricants, expect them to reinforce your doubts. You will hear how large their research departments are and that a smaller company couldn’t possibly offer better products. You will be shown carefully selected laboratory tests intended to clearly show their products to be technologically superior. Every means will be exerted to prevent a head-to-head comparison with Royal Purple at the equipment level, where the outcome is already known to them. They would have you continue to make (without all of the facts) a decision that falls within your comfort zone. Case study synopses that follow clearly illustrate why this is not in your best interests.

RESULTS-ORIENTED DECISION-MAKING

Royal Purple encourages you to make an informed decision based on actual results in your own equipment. Ask your maintenance and operations departments to select candidate equipment for your own evaluation of what Royal Purple lubricants can do for you. After all, it is your money.

CASE STUDIES

The following case studies have been assembled according to whether the primary benefit reported from using Royal Purple lubricants was energy savings, maintenance savings or improved production. In virtually every instance, Royal Purple lubricants replaced major brand lubricants that met all of the equipment manufacturer’s requirements. In multiple examples, Royal Purple replaced another synthetic oil. It is important to note that (in most of the case studies) the equipment involved did not suffer from mechanical defects nor did the equipment lack proper maintenance. Improved performance resulted because Royal Purple lubricants were able to mitigate the effects of the operating conditions in which the equipment was required to operate. All of the reported energy studies are inclusive of every piece of equipment selected for evaluation so as to be representative of what might be expected across a broad population of equipment.

ENERGY SAVINGS

OKLAHOMA PAPER MILL

• 3 pumps and 2 gear boxes changed to Royal Purple
• 4.1% energy savings valued at $4,725 per year

TAKEDA CHEMICAL COMPANY

• 2 mixers and 7 pumps
• 2.52% energy savings valued at $3,462
• 19-day payout on increased cost of oil

DAKOTA GASIFICATION COMPANY

• Three (3) 20,000 HP CO₂ Compressors
• Change R&O ISO 32 oil to Royal Purple Synfilm GT 32
• 2.7% power savings
• More than $350,000 annual energy savings

GIANT INDUSTRIES REFINERY

• 7 API pumps
• 8.5% energy savings valued at $72,302 per year

CAMPBELL SOUP COMPANY

• 3 ammonia refrigeration compressors
• $43,600/year energy savings from less than $3,000 of Royal Purple oil
• 25-day payout on total cost of oil

MICHELIN TIRE COMPANY

• 14 pieces of equipment (pumps, conveyors, compressors)
• 3% energy savings valued at $36,936 per year

FRITO-LAY

• 4 pieces of equipment
• 2%, 4.5%, 5% and 5.4% energy savings
• $1.56 savings per HP per every 1,000 hours of operation

AHMSA STEEL MILL

• 1 rotary screw air compressor (500 HP)
• Four 4-stage centrifugal air compressors (32,000 HP)
• Includes digital and analog air flow measurements
• Royal Purple Synfilm 46 replaced major brand ISO 46
• Energy Savings:
  • 10.5%, 3.75%, 2.98%, 3.17% and 3.33%
  • 6,074,385 kw/yr = $547,000 per year

INDUSTRIA DEL ALCALI S.A. DE C.V. (ENERGY SAVINGS PROJECT)

• 13 pieces of equipment (vacuum pump, cooling tower fans and dryer/mixer)
• 11.8% energy savings (ranged from 5.99% to 21.86%)
• $32,765 estimated annual value of savings at $0.06 per kwh

SUN CHEMICAL

• I-R Centac compressor: 3,000 HP
• 4.1% power savings valued at $42,315 per year

PINELLAS COUNTY WATER

• 9 gear reducers
• 7.8% power reduction valued at $17,520 over 2 years
• 63-day payout on total cost of oil

COFFEYVILLE RESOURCES REFINERY

• 3 API pumps on oil mist (200, 100 and 60 HP)
• Oil changed to Royal Purple Synmist
• 8.34% average energy savings
• $49,018 estimated annual savings projected for all 1,322 active pumps

DOFASCO STEEL

• 2,000 HP bay water pump (cooling water)
• Cooler erosion caused unavoidable water contamination
• Mineral oil drained weekly due to emulsification with water
• Have run 3 continuous years on same oil since changing to Royal Purple Synfilm (simply drain off water)
• Temperature down 15 degrees and vibrations down 50%
• $55,000 annual savings in parasitic steam loss

FORD MOTOR COMPANY

• 3 Atlas Copco GA90C 125 HP rotary screw compressors
• Oil changed to Royal Purple Synfilm 46
  • 1) 5.8% energy savings at $3,625 per year
  • 2) 4.8% energy savings at $3,315 per year
  • 3) 6.7% energy savings at $4,973 per year

CHICAGO COKE

• 6 Sullair rotary screw air compressors
• Royal Purple Synfilm 32 replaced OEM’s synthetic fluid
• 6% average energy savings and 10-degree reduction in temps
• $10,176 per year reduced cost of lubricants
• $35,662 per year energy savings

ALBRIGHT AND WILSON AMERICAS

• 3 pieces of equipment (cooling tower, pump and agitator)
• 3.2% combined energy savings

ALTURA ENERGY

• American split case pump, 9 stage with 1,250 HP motor and Lufkin gear box
• 16.26% energy savings with Royal Purple Synfilm 68 valued at $77,619 per year

HOECHST CELANESE

• Riley-Stoker 150 HP coal pulverizer
• 4.1% energy savings
• $107 cost of Royal Purple oil
• $1,879 annual energy savings
• 21-day payout on total cost of oil

PHELPS – DODGE

• Blower in SO₂ service (5,000 HP/4:1 speed increaser)
• Royal Purple Synfilm GT 32 replaced major brand turbine oil
• $18,000 per year energy savings with 4.5 Amp drop
• Bearing temperature down 25 degrees

SONOCO PRODUCTS PAPER MILL

• Feed water pump; 200 HP; 3,600 RPM
• 18.2% energy savings (16 AMPS)
• $5,131 per year savings for less than $10 of oil
• 17-hour payout on total cost of oil

NEXFOR FRASER PAPERS

• Control crown roll on paper machine
• Changed major brand PM 220 to Royal Purple Synfilm GT 220
• 11% machine speed increase (production)
• 34% increase in PLI (machine load)
• 32-degree reduction in oil temperature
• $27,945 per year energy savings

• Calendar stack roll
• Change major brand PM 220 to Royal Purple Para-Syn PM 220
• $19,248 per year energy savings

• Super-calendar bottom control roll (3,000 ft/min)
• Temperature-controlled cooling water system
• Changed major brand synthetic 220 to Royal Purple Para-Syn PM 220
• 70% reduction on cooling water usage (50,000 gallon/day average)

MAINTENANCE SAVINGS

COFFEYVILLE RESOURCES REFINERY

• Major annual rebuilds on I/R Centac compressor at $240,000 each
• Replaced PAG synthetic oil with Royal Purple Synfilm GT
• Only one minor repair after 4.5 years

ENTERPRISE PRODUCTS GAS PLANT

• 15 York Centrifugal Compressors in DIB (ISO butane) service
• 7 to 10 failures each year at $60K to $150K each
• Changed to Royal Purple Synfilm NGL
• $800,000 per year estimated annual savings

• 40 horizontal split-case pipeline pumps
• One babbitted sleeve bearing failure every 6 weeks
• Only 1 failure every 6 months with Royal Purple Synfilm 32

• 200 fin fans
• 2 to 3 failures per week
• One failure per month with Royal Purple grease

• Cooling tower gear boxes
• Annual bearing replacements
• Exceeding 5 years with no replacements with Royal Purple

• Solar genset turbine
• Two oil pump failures and subsequent coast downs on same turbine
• Royal Purple Synfilm prevented potential $325,000 damage per incident

MAJOR OIL REFINERY

• 77 bad actor pumps changed to Royal Purple Synfilm and Synfilm GT
• 74 pumps removed from bad actor list one year later

TESCO SERVICES

• Linde BPV130 positive displacement hydraulic pumps in top-drive service
• 60 pump failures per year at a cost of $2,240 each
• 20 pump motor failures per year at $8,100 each
• Changed to Royal Purple Marine Hydraulic Oil
• Temperatures dropped 50 degrees (from 180-190° F to 130-140° F)
• No pump failures during the next 18 months
• No hydraulic pump motor failures during the next 18 months

DOW CHEMICAL

• 30 oil-misted ANSI hot water pumps
• 18 bearing failures per year
• Changed major brand 68 to Royal Purple Synmist 68
• One bearing failure over next 3.5 years (vs. 68 historically over same period)

PREMARC CORPORATION

• Two 18,000-pound fork trucks with Allison TRT2001 transmissions
• 1 to 2 transmission failures per year, each at $6,000 per incident
• Changed oil to Royal Purple CMT 30
• Temperatures dropped from 230° F to 180° F
• No failures in 6 years
• 6-year savings valued at over $50,000

KING FISHER MARINE

• 8 to 9 engine replacements per year historically with major brand marine engine oil
• Only 7 engine replacements in the last three years with Royal Purple Motor Oil
• 6-month life on turbochargers at $1,000 each
• No turbocharger replacements in over two years with Royal Purple
• Annual clutch replacements at $10,000 to $30,000 each, depending on damage
• No clutch replacements in 2 years with Royal Purple on 3 boats where this was a problem
• Oil drain intervals extended six-fold (from 350 hours to 2,100 hours) with Royal Purple

CLEAR LAKE COGENERATION

• 450 HP vertical 3,600 RPM motors driving 14 stage condensate pumps
• Bearing life 4 to 7 months: failure severely damaged motor and pump ($14,000 per occurrence)
• Changing oil to Royal Purple reduced temps from 400° F to 160° F and increased bearing life to over 2 years

DOLARSTAN BAYER SPANDEX

• 18 Klaus Union magnetically driven Dowtherm pumps
• Pumps began to fail 90 days into plant startup due to short oil life
• Changed major brand synthetic oil to Royal Purple Synfilm GT
• Failures stopped and oil change intervals extended to 1 year

CLARK REFINING

• 8 hydrogen gas compressors (2-year reporting period)
• 0 failures on 6 compressors using Royal Purple Synfilm Recip. 100
• 4 failures on 2 compressors using another oil

UNION CARBIDE

• Centrifuges and gear boxes
• 8 to 10 gear box failures per year at more than $10,000 each
• 1 failure in following year using Royal Purple Synfilm GT 150

NEXFOR FRASER PAPERS

• Greased bearings in #7 and #8 paper machine wet end
• Changed major brand synthetic grease to Royal Purple Paper Mill Grease
• 30-degree average bearing temperature reduction
• Every 4-week relubrication cycle extended to 12 weeks
• 5 unscheduled outages due to bearing failures the previous year
• $129,250 value of lost production
• 0 bearing failures the next 19 months with Royal Purple
• $10,000 annual savings from reduced grease purchase

PRODUCTION IMPROVEMENTS

J-POWER (WIND TURBINES)

• Large Mitsubishi® and 1.75 MW Vestas wind turbines
• Changed from major EP 320 mineral gear oil and major synthetic 320 gear oil to Royal Purple Synfilm GT 320
• Turbine output increased by 5% and 5.1% at year-over-year average wind speed
• Increased turbine output valued at over $200,000 (USD) per year

ENTERPRISE PRODUCTS GAS PLANT

• Production cutbacks due to high temps in 10,000 HP Demag Delavel compressor in summer months
• Royal Purple Synfilm GT reduced temps from 225° F to 170-175° F (a 50-degree reduction), eliminating the need to reduce production in summer months

COFFEYVILLE RESOURCES

• Two I/R HHE reciprocating compressors in hydrogen gas service
• Maintenance error loaded crank cases with water
• Synfilm protected crank shaft and avoided failures
• $100,000 maintenance savings for each compressor
• Two days’ minimum lost production avoided (valued at $4.5 million per day)

DEEP MARINE TECHNOLOGY

• R.O.V. (deep subs) operate in cold water (7,000-8,000 ft)
• Tool calibrations must be done on deck before each job
• Calibration takes 2 to 3 hours due to overheating hydraulics (on-deck run times limited to 90 seconds)
• Requires only a single 8-minute to 9-minute run since changing to Royal Purple Syndraulic (no overheating)
• $10,000 savings in vessel time

ESTIMATE YOUR OWN ENERGY SAVINGS POTENTIAL

OPERATION HOURS

Note: Base Rates do not reflect “Peak Load Charges” and may not fairly represent the actual cost of service.

MAJOR OIL REFINERY

Ultraformer pump failing and would shut down unit production. Major brand Synthetic 32 changed to Royal Purple Synfilm 32 while operating (1 quart of oil). Vibrations, temperatures and noise reduced to a level where repair was no longer deemed necessary, and pump remained in service for 2 more years.

• $50,000 savings on pump repair
• Downtime avoided savings (more than $100,000 per day)

AMOCO CHEMICAL

• High-pressure reciprocating ethylene compressors
• Changed from competing synthetic oil to Royal Purple NGL-NS 460 in cylinders, packing and crank case
• Machine utilization went from mid-60% to high 90% range
• Maintenance cost reduced by 50%
• Increased production valued at millions of dollars

DOW CHEMICAL

• 12,700 HP electric motor driving polypropylene extruder gear box
• Journal bearing temperature would exceed critical level (85° C) on high-density product runs, necessitating production rate cutbacks to remain operational
• Major brands synthetic oil 68 changed to Royal Purple Synfilm GT 68
• Bearing temperature decreased 6-8° C and never exceeded 78° C
• Production was increased by 18,000 pounds per hour
• Subsequently, major brand EP gear oil in extruder gear box was changed to Royal Purple Synergy
• 3.1% energy savings valued at $22,105 per each 1,000 hours of operation

BASF CHEMICAL

• 10,000 HP A-C Acetylene Compressor
• Operating for over 4 years on common lube console with the same 3,500 gallons of Royal Purple Synfilm 32
• Frequent upsets introduce large volumes of water into system, which is regularly drained from the sump.
• After an upset caused the compressor to run in reverse, it was taken down for maintenance.
• The oil drained from the sleeve bearing had over 25% water in it, yet neither the bearing nor shaft showed any damage.

CHINA STAR BULLET TRAIN

• Project design called for average speeds of 200 kph (125 mph)
• Zhuzhou Electric Locomotive’s 1,250 kw traction motors
• Greased NSK motor bearings would overheat at 160 kph
• 26 greases were tested prior to grease selection
• 200 kph speeds easily reached after changing to Royal Purple UPG #2 Grease
• NSK elected to test Royal Purple Synfilm GT vs. recommended gear oil in the drive gear
• Royal Purple Synfilm GT ran cooler by 20° C while reducing bearing vibrations by 50%
• All lubes were changed to Royal Purple
• Train set new China speed record of 321.5 kph (200 mph) and functioned well for over 80,000 km of high-speed testing

KING FISHER MARINE

• Pump shaft bearing failing on dredging job
• Oil changed to Royal Purple Synfilm 100
• High temps and noise were abated
• Pump operated for 91 more days to complete two jobs
• Upon disassembly, the 8” bearing fell in two

WEATHERFORD (CASPIAN SEA PIGGING JOB)

• 2,000-mile 36” oil pipeline
• 58-1500cfm Sullair screw compressors/Cummins diesel-driven
• High ambient temps caused repeated high-temperature trip-outs in compressors
• Unable to maintain contract schedule
• Changed major brand 68 synthetic oil to Royal Purple Synfilm 68
• 15-degree temp reduction in compressor ended trip-outs
• 6,000 hour oil changes

LEADING ALUMINUM ROLLING MILL

• Aluminum foil production computer controlled at optimum 4,000 ft/min
• Production on 15 to 20 hottest days of year would slow to 2,500 ft/min due to elevated bearing temperatures and vibrations
• Constant 4,000 ft/min year-round with Royal Purple Synmist 320
  • Including 12-hour period when bearings inadvertently operated without cooling water
• ADDITIONAL BENEFITS:
  • Oil feed rates reduced 50%
  • Bearing failures reduced from 2 per year to 0 in 5 years (5-year savings of $430,000)

MAJOR OIL REFINERY

• Howden vapor recovery compressor
• Lubricant repeatedly contaminated with vapors from headspace from ships
• Frequent lube oil changes with filter changes up to 8 times per day
• Lube viscosity loss and binding of filters often made compressor inoperable (cost up to $250,000 per missed ship)
• Royal Purple Synfilm NLG totally eliminated problem

ROYAL PURPLE, LLC.

One Royal Purple Lane

Porter, TX 77365

PHONE

(281) 354-8600

TOLL-FREE

(888) 382-6300

FAX

(281) 354-7600

RoyalPurpleIndustrial.com

Copyright ©2024, Royal Purple, LLC. All Rights Reserved.

HISTORY

Royal Purple produces a wide range of high-performance synthetic lubricants for nearly every consumer and industrial application. Its founder, John Williams, was a pioneer in the development of high-performance synthetic lubricants. Collectively, Royal Purple’s formulators have more than 200 years of expertise in developing state-of-the-art lubricants. Unlike companies that primarily focus on fuel and other petroleum byproducts, Royal Purple’s sole mission is to develop products that significantly outperform other synthetic-based and mineral-based oils. Today, Royal Purple is widely recognized as both a super-premium line of consumer automotive products and as a leading primary lubricants supplier to industrial end markets competing head-to-head with the largest oil companies. Royal Purple is distributed in countries around the world, including the United States, Canada, Mexico, Australia, China, Italy, Japan and the United Kingdom. Royal Purple was acquired in 2012 by Calumet Specialty Products Partners (CLMT): a leading refiner and processor of specialty hydrocarbon products headquartered in Indianapolis, Indiana.
